T550+IR4+Conveyor
I.C.T
smt pcb metal coating machines
| Số: | |
|---|---|
The SMT PCB Coating line is engineered for high-precision PCBA conformal coating and gluing applications. Multi-axis robots with adjustable valves provide uniform coverage across complex PCB surfaces. The line includes automated conveyors with adjustable width and height, IR/UV curing ovens with independent cooling, and optional CCD vision monitoring for quality assurance. PLC and PC-based control allows real-time adjustment of coating parameters, speed, and curing intensity. This line is designed for high-throughput production, reducing material waste while maintaining consistent coating quality across various PCB assemblies.
The coating robots operate along multiple axes to deliver repeatable, uniform coverage. Adjustable spray valves handle different adhesives, conformal coatings, and glue viscosities. Height detection and edge recognition prevent over- or under-coating. Single- and double-sided coating is supported, minimizing material waste while maintaining consistent layer thickness. The robots’ precision ensures that each PCB or LED module receives the correct coating amount, critical for high-density SMT and DIP assemblies where component spacing is tight.
The conveyor system uses durable aluminum and stainless steel chains with stepper motor drive, providing stable movement. Width and height are adjustable to fit various PCB sizes. Push and buffer mechanisms ensure precise board positioning and smooth transition between stations. Fiber optic sensors detect PCB presence, preventing misalignment or collisions. Optional return and spacing adjustment functions allow flexible line configurations. This setup supports high-density production while maintaining consistent, high-quality coating across all boards.
The IR/UV curing zones deliver uniform heat and light exposure for rapid curing, while independent cooling zones maintain safe board temperatures. PLC-based controls adjust conveyor speed, curing intensity, and process parameters in real time. Optional CCD vision systems monitor coating uniformity, identifying defects early in the process. Integration of coating, curing, and inspection ensures consistent quality, reduces manual oversight, and allows high-volume SMT and DIP PCB production with reliable results for adhesives, conformal coatings, and glues.
The coating line works alongside I.C.T’s SMT and DIP production equipment, including pick-and-place machines, wave/ selective soldering units, jet dispensers, AOI inspection, and PCB depaneling machines. Integration ensures continuous production, consistent board handling, and inspection after coating. This combination improves throughput, minimizes rework, and maintains uniform coating quality. The full line provides automated, reliable solutions for high-volume PCB and LED module production, from component placement through coating and final inspection.
| Product Name | Purpose in PCBA Coating Line |
|---|---|
Applies precise protective coatings to circuit boards for dustproof, waterproof, and explosion-proof protection. | |
Hardens coatings with IR or UV light, ensuring durable and strong protection. | |
Transports circuit boards smoothly through the coating line for efficient processing. | |
Provides and stores PCB for the production line, ensuring smooth input and output. | |
| Conformal coating AOI | Inspects coating quality and detects defects to ensure high standards. |
In December 2025, I.C.T delivered three production lines—SMT, DIP, and Coating—to a Saudi Arabian automotive electronics manufacturer. I.C.T engineers provided on-site installation, commissioning, and training for the client’s staff. Earlier, the customer visited I.C.T in June 2025 to inspect the equipment and assess the solutions. After smooth commissioning, the client awarded I.C.T engineers honorary certificates, recognizing professional service and the reliable performance of the full SMT, DIP, and coating solution for establishing their new ODM factory for independent R&D, design, and production.
I.C.T supports customers across the full SMT, DIP, and coating factory process, not just single machines. Pre-delivery planning includes PCB types, coating materials, line speed, workshop layout, and future expansion. Post-delivery, support includes installation, commissioning, operator training, maintenance guidance, and process optimization. Engineers ensure seamless integration of coating, curing, inspection, handling, and depaneling systems. New factories receive guidance from layout to trial production, while existing factories benefit from optimized workflow, balanced line operations, and high-quality PCB coating results.
Customers appreciate I.C.T for hands-on guidance and responsiveness. In full SMT projects, they emphasize machine stability, engineer expertise, packaging protection, and quick post-sale support. Engineers provide clear instructions, helping operators reduce errors and improve throughput. Export packaging ensures safe delivery. Technical issues during installation or production are addressed promptly by coordinated sales and engineering teams. This support enables customers to launch new lines, scale production, and maintain consistent high-quality coating across PCBs and LED assemblies.
The PCBA Conformal Coating Line is CE and ISO9001 certified. Quality management includes component inspection, assembly verification, function testing, packing confirmation, shipment tracking, installation records, and after-sales service. Procedures ensure reliable, repeatable coating performance, minimize risk, and maintain consistent results in high-volume SMT and DIP PCB production. Each unit is validated to guarantee uniform application of adhesives, conformal coatings, and glues throughout the production workflow.
I.C.T provides complete SMT, DIP, coating, dispensing, assembly, and robotics solutions. In-house R&D, production, engineering, sales, and service teams support clients from planning to stable production. I.C.T has completed projects globally, providing equipment, installation, training, and process optimization. Beyond supplying machines, I.C.T builds new lines from 0 to 1 and upgrades existing facilities from 1 to 10, enabling scalable, precise, and reliable SMT PCB and LED coating manufacturing systems.
